AX11 IO Controller
Integrate more of your building infrastructure.
Meet the AX11
Verkada Elevator Access Control
Bring the plug-and-play simplicity of Verkada Access Control to your building’s elevators with the AX11. Integrate with existing access hardware or deploy Verkada end-to-end for elevator access and native video integration.
-
Control Access for Up to 16 Floors
Securely make all entry decisions for 16 floors across multiple elevators and readers on one unit.
-
Integrate with Door Readers
Manage access to different floors of a building with seamless integration to Verkada or Wiegand readers.
-
Simplified Ongoing Management
Control floor access, view access events, manage users and more in Verkada’s intuitive cloud-based platform.
Best of Both Worlds with Event Bridge
Event Bridge with the AX11 allows you to continue using your existing access control or alarm system without a full system migration. Add video analytics to your doors, even if they are not secured by Verkada. At the same time, access events will stream directly to Command to improve visibility across entrances and exits.
Native Camera Integration
Door Open & Held Open
Door Activity Over Time
SMS / Email Alerts
Video Analytics
Reporting
Additional IO Applications
The Verkada AX11 IO controller integrates more physical infrastructure into Verkada Command to better manage sensors, switches and peripherals with Verkada’s single-pane-of-glass platform.
Door DPIs for Analog Doors
Generate camera events for all Door Position Indicator (DPI) events, even for analog doors.
Button / Intercom Unlocks
With the AX11, you can unlock entrances via button or intercom input events.
On-Wall Defibrillators
Generate camera events and notifications anytime a defibrillator is opened.
Art Disturbance Sensors
Monitor precious artwork and other valuable artifacts with sensor inputs.
Shoplifting Tags
Protect physical property and assets with physical shoplifting tags and native camera events.
AUX Monitors
Monitor for events and trigger alerts with auxiliary monitors, native camera events and alerts.
Key Features
- More Versatility with 16 Inputs & 16 Outputs
- Instant Video Integration and Insights
- Cloud-Based Software and Management
- Limitless Scalability Across Buildings
- Bring Existing Infrastructure into Command
How it Works
- 1
Connect IO devices to the AX11 - elevators, AUX devices, DPIs and more
- 2
Pair the AX11 with a Verkada Camera for native tagging of video events, alarm triggers
- 3
Monitor events across devices, even on analog doors.
- 4
Create custom notifications and quickly export reports to speed up investigations.
How it Works
Product Specifications
- Power Consumption60W Max
- Power Supply110-240VAC
50-60Hz - Inputs16 Dry Inputs
Nominal 5VDC - Relay Outputs16 Dry Relays
1A/24VDC Contacts - Aux Power2 External Outputs
1A/12V Power Each
2A Combined Max - DimensionsLength: 415.6mm / 16.3in
Width: 319.6mm / 12.6in
Height: 111.7mm / 4.4in - Weight8.3kg / 18.3lb
- Operating Temperature0°C ~ 50°C (32°F~ 122°F)
5-90% Humidity - ComplianceFCC, CE, UL 294, UL 62368-1/CSA C22.2, CAN/ULC-60839-11-1:2016, NDAA
- ConnectivityEthernet: 100/1000Mbps RJ-45 cable connector for network connection
USB 2.0 - Included AccessoriesSetup guide, screw pack
- Mounting OptionsDrywall anchors (M8) and screws (M5)
Frequently Asked Questions
-
What is the main use case for the AX11?
With 16 inputs and 16 outputs, the AX11 IO Controller is designed to add flexibility to existing access control systems. With the AX11, customers have more options to remotely lock or unlock doors, monitor entryways, and secure critical assets.
-
How do I secure elevators with the AX11?
The AX11 allows you to access control up to 16 elevator floors through the AX11’s 16 inputs and 16 outputs. With the AX11, each floor serves as an access point and can take inputs from Verkada readers or third-party Weigand readers. At the same time, native video integration means that anytime you have an elevator event, you can also generate camera events.
-
How do I install the AX11?
The AX11 is designed with many features that make installation incredibly simple, including removable connectors, an integrated power supply, and a detachable mounting plate. Bringing the product online is also straightforward. Simply connect to power and ethernet, and the device is ready to be added to Command.
-
Can events from the AX11 generate Camera or Alarm events?
Yes, events generated by the AX11 can be cross-referenced with security camera footage and ingested by our alarms and professional monitoring offering to make any Verkada deployment even more integrated and scalable.
-
Does the AX11 integrate with motion sensors or other 3rd party sensors?
The AX11 can be used to integrate multiple additional 3rd party sensors, switches, and peripherals, which can then be managed through Command in our intuitive centralized web-based interface.
-
How much does the AX11 cost?
The AX11 is available with our industry-leading 10-year warranty at a hardware list price of $1,599 and software licenses of 1, 3, 5, and 10 years. To learn more, contact a member of our team at sales@verkada.com.
Learn More About the AX11
Learn More
Discover how the AX11 integrates third party sensors, switches and peripherals into the Command interface.
